Content:

 1. Introduce
Tripath  amplifier board,class T amplifier,digital amplifier boards

 SL-A17 is new stereo class T amplifier, it is 20W(4ohm) continuous  average per channel class-T digital audio power amplifier, use Tripath's  proprietary power processing technology, class-T amplifiers offer both the audio  fidelity of Class-AB and the power efficiency  of class-D  amplifier.

2. Application

 <!--[if  !supportLists]-->·         <!--[endif]-->Power speaker

<!--[if  !supportLists]-->·         <!--[endif]-->Digital product

<!--[if  !supportLists]-->·         <!--[endif]-->Computer and PC multimedia

<!--[if  !supportLists]-->·         <!--[endif]-->Television

<!--[if  !supportLists]-->·         <!--[endif]-->Battery powered  system

<!--[if  !supportLists]-->·         <!--[endif]-->DVD player

3.  Feature

<!--[if  !supportLists]-->·        <!--[endif]-->"Audiophile "quality sound
0.03% THD+N  @10W 4ohm
0.1% THD+N@12W 4ohm

     0.18% IHF+IM@1W 4ohm

<!--[if  !supportLists]-->·        <!--[endif]-->High power
25W@4 ohm,10% THD+N  Vdd=14.6V
22W@4 ohm,10% THD+N Vdd=13.5V
13W@8ohm ,10%  THD+N Vdd=13.5V

<!--[if  !supportLists]-->·        <!--[endif]-->Class-T architecture

<!--[if  !supportLists]-->·        <!--[endif]-->High efficiency
88% @12W 8ohm
81% @  20W 4ohm

<!--[if  !supportLists]-->·        <!--[endif]-->Dynamic  range=99dB

<!--[if  !supportLists]-->·        <!--[endif]-->Mute and sleep Input

<!--[if  !supportLists]-->·        <!--[endif]-->Integrated Gate Drive Supply　

<!--[if  !supportLists]-->·        <!--[endif]-->Over-current protection

<!--[if  !supportLists]-->·        <!--[endif]-->Over-temperature protection

<!--[if  !supportLists]-->·        <!--[endif]-->IC package: 32-pin  SSOP

<!--[if  !supportLists]-->·        <!--[endif]-->PCB material is FR4, thickness  1.6MM

<!--[if  !supportLists]-->·        <!--[endif]-->The dimension is 112mm*69mm
